Technical Specifications

RaceBox drawing - front RaceBox drawing - right
  • Weight (including suction cup): 260 grams (9.2 oz.)
  • Memory capacity: 256 drag sessions with up to 100 runs each, 128 track sessions with up to 100 laps each, 64 tracks with up to 7 configurations each, up to 5 sectors per configuration; Over 8 hours total driving time; Single track predictive mode reference lap, single drag predictive mode reference run.
  • Battery: integrated 2500 mAh LiPo
  • Recommended charger: 2A USB Type A. Most modern smartphone chargers should work
  • Charging port: USB Type C
  • Charging time: less than 3 hours to 100% charged
  • Usage on battery: up to 8 hours driving with WiFi off, 4 hours with WiFi enabled, 2 hours with WiFi enabled and constantly connected to the app
  • External antenna compatibility: Active antenna with standard SMA connector, less than 30mA@3.3V
  • Mounting compatibility: Should work with most Go-Pro-compatible mounting kits
  • GPS receiver: 10Hz GPS, GLONASS and SBAS, -167dBm sensitivity with built-in 35dB gain antenna
  • Accelerometer: 1kHz sampling rate with +/- 4g scale and 0.001g sensitivity
  • WiFi: 802.11 b/g/n 2.4GHz, up to 400 meters range, WPA2 encryption
  • Display: TFT-LCD, 2.5" 320x240, full color (though we use it mostly with high-contrast black&white interface), adjustable brightness up to 300 cd/m2 and contrast of 500:1
  • Environmental compatibility: -20 to 70°C (-4 to 158°F), minimal water protection
